Intensity EX 4

Please call for price

Options Quantity
Intensity Ex 4 - 4 Cahnnel Stim Device
RM-52-DQ7000
SKU: N/A Categories: , ,

The InTENSity EX4 is an advanced four-channel electrotherapy system offering the practitioner a wide range of treatment options in one user-friendly, ergonomic design at a fraction of what other systems would cost. Equipped with a color, touchscreen menu-driven interface, the InTENSity EX4 intuitively groups and displays clinical protocols, guiding clinicians step-by-step to ensure the ideal therapeutic treatment. Parameters can be easily selected and adjusted. Clinicians can choose to use preset clinical protocols or customize their own. The comprehensive library provides recommended electrode placement to ensure better treatment outcomes and improved clinic efficiency.

FEATURES & BENEFITS:

• 4 channels of independent stimulation – can be used in combination (linked) or totally independent
• Independent intensity and parameter controls for each channel
• Bilingual (Spanish/English) touchscreen user-friendly interface
• Multiple waveform electrotherapy: Interferential, Premodulated, TENS (Symmetrical Biphasic, Asymmetrical Biphasic, RAAS*), NMS, Russian, High Volt, and Microcurrent
• Rapid Agonist Antagonist Sequencing (RAAS*) replicates typical firing patterns of muscle contractions during functional movement for the best therapeutic outcome
• Comprehensive full-color graphic anatomical and pathological libraries with recommended electrode placement
• “Favorites” feature stores up to 99 user-defined protocols for future use
• Sleek, user-friendly, ergonomic design for table top or therapy cart use

BIPHASIC (TENS):
Waveforms: Asymmetrical & Symmetrical Biphasic Rectangular
Mode Selection: CC or CV
Pulse Amplitude: CC: 0 – 200 mA
CV: 0 – 200 V
Pulse Width: 20 – 400 ?sec
Pulse Frequency: 1 – 250 Hz
Treatment Time: 1 – 60 minutes

NEUROMUSCULAR STIMULATION (NMS)
Mode Selection: CC or CV
Pulse Amplitude: CC: 0 – 200 mA
CV: 0 – 200 V
Pulse Width: 20 – 400 ?sec
Interphase Interval: 120 ?sec
Pulse Frequency: 1 – 200 Hz
Ramp: 1s, 2s, 5s
Cycle Time: Continuous, 10/10, 10/20, 10/30, 10/50, Custom
Treatment Time: 1 – 60 minutes

MICROCURRENT
Frequency: 0.1 – 1000 Hz
Polarity: Positive, Negative, Alternating
Pulse Amplitude: CC: 0 – 1,000
Cycle (Fixed): 50%
Ramp (Fixed): 1s
Treatment Time: 1 – 60 minutes

IF-4P TRADITIONAL
Waveform: Sinewave
Mode Selection: CC or CV
Vector Scan Auto: 20% – 100%
Manual: 0° – 90°
Carrier Frequency: Carrier F: 2 – 10 KHz
Beat Low: 1 – (Beat H.)
Beat High: (Beat L.) – 200 Hz
Pulse Amplitude: CC: 0 – 200 mA
CV: 0 – 200 V
Treatment Time: 1 – 60 minutes

IFC-2P PREMODULATED
Waveform: Sinewave
Mode Selection: CC or CV
Vector Scan: Auto: 20% – 100%
Manual: 0° – 90°
Carrier Frequency: Carrier F: 2 – 10 KHz
Beat Low: 1 – (Beat H.)
Beat High: (Beat L.) – 200 Hz
Pulse Amplitude: CC: 0 – 200 mA
CV: 0 – 200 V
Ramp: 2s
Treatment Time: 1 – 60 minutes

RUSSIAN
Carrier Frequency: 2.5 KHz
Frequency: 20 – 100 Hz
Duty Cycle: 10% – 50%
Mode Selection: CC or CV
Pulse Amplitude: CC: 0 – 100 mA
CV: 0 – 100 V
Ramp: 1s, 2s, 5s
Cycle Time: Continuous, 10/10, 10/20, 10/30, 10/50, Custom
Treatment Time: 1 – 60 minutes

HIGH VOLT PULSED CURRENT (HVPC)
Frequency: 1 – 120 Hz
Polarity: Positive or Negative
Phase Duration: 100 ?sec
Pulse Amplitude: CV: 0 – 500 V
Ramp: 1s, 2s, 5s
Treatment Time: 1 – 60 minutes
